模温机


控制机;温度控制机;模具温度控制机模具温度控制机特点1、电脑触摸式控制,操作简单易懂。2、日本进口微电脑双组P.I.D温度控制表,触摸式内储、自动演算,省电35%以上。3、安全保护及故障指示系统完善。4、进口高级组件,使用年限长。5、升降温速度快,温度精确稳定。6、独特的又功率加热设计,适合不同温控场所使用,节能效果明显。7、不锈钢一体成型,管捐小,加熟

价格:面议

控制机;温度控制机;模具温度控制机

模具温度控制机特点
1、电脑触摸式控制,操作简单易懂。
2、日本进口微电脑双组P.I.D温度控制表,触摸式内储、自动演算,省电35%以上。
3、安全保护及故障指示系统完善。
4、进口高级组件,使用年限长。
5、升降温速度快,温度精确稳定。
6、独特的又功率加热设计,适合不同温控场所使用,节能效果明显。
7、不锈钢一体成型,管捐小,加熟均匀。
8、开机自动排气功能。
9、模具回水温度检测表。

Characterstic
1.Micro-processing controller,easy opration.
2.Japanese Import microcomputer palr of group P.I.D temperature controls the scheduling,touches the type storage,the automatic calculation,saves above electricity35%.
3.The safekeeplng of security and the failue indication system is perfect.
4.The import high-quality module,the service life is long.
5.Rises to decrease temperature the speed qulckiy the temperature percise is stable.
6.The unique double power heats up the design,suits the isothermia not to control the place use,the energy conservation effect is obvious.
7.A stainless steel body takes shape,the tube damages slightly,heats up erenly.
8.Automatically opening machine and exhaust function.

机型Model单位UnitAWM-10AWM-20AWP-10AWMD-10
温控范围Controlrange120℃
温控精度Temp.controlaccuracyPID±1℃PID±1℃PID±1℃
电源Power
AC3∮380V50HZ3P+E(5M)
传热媒体Heattransfermedium
水WATER
冷却方式Coolingmethod
直接冷却INDIRECTCOOLING
加热能量HeatingcapacityKW9(3)9(3)9(3)9(3)+9(3)
泵浦马力PumppowerHP1121+1
量大泵浦流量Max.PumpfolwL/MIN15315323270+70
冷却水压力CoolingwaterpressureKG/CM22222
最大电力消耗PowersupplyKW10101120
警报功能Alertfunction
缺相/缺水/超温/过载
冷却水配管CoolingwaterpipeINCH1/21/21/21/2
循环水配管CirculationwaterpipeINCH3/8*43/8*43/8*4(3/8*4)*2
外型尺寸LxWxHMM800*325*640800*325*640800*325*640800*550*640
重量WeightKG626267105
